Physics team 3B SEA 1006804. Radioactivity, 10 experiments

Set of devices for carrying out 10 fundamental student experiments on radioactivity. In a stable plastic box with formed foam insert for the devices and with transparent lid. Includes CD with experimentation instructions. The experiments are mounted and carried out in a small space, however clearly, on the base plate that is delivered with the equipment.
To determine the pulses per second, the application of the Geiger counter GAMMASCOUT 1002722  (U111512) is recommended, which is not part of the scope of delivery.

Scope of supply:
1 Plate working size 340x250 mm²
3 Working diagrams
1 Support for the radioactive source and the deflection magnet
1 Deflection magnet
1 Thorium I emitter (welding wire)
2 Aluminum plates, 0.5 mm
1 Aluminum plate, 1 mm
1 Lead plate, 2 mm, in plastic wrap

Includes 10 experiment guides for radioactivity:
• Determination of the background count per second
• Determination of pulses per second of different radioactive preparations
• Statistical distribution of counting pulses
• Determination of the equivalent dose power of radioactive preparations
• Penetrating power and range of radioactive radiation
• Deflection of alpha radiation and beta radiation in the magnetic field*
• Absorption of alpha radiation*
• Absorption of beta radiation*
• Absorption of gamma radiation*
• Law of the square of distance

REQUIRED:
- Geiger counter Item No. 1002722
- Spike radiation 226 Ra, 4 kBq Article 1006797
